APPLICATIONS
• Light and Heavy Duty
• Hazardous Environment
• Power Transmission
• Signal Telemetry
• ROV
SPECIFICATIONS
Keying: Metal to metal key for positive alignment
Housing Material: 316 SS passivated per QQ-P-35 Type VI with naval bronze engaging nut.
Contacts: Contacts gold plated per MIL-G-45204
Threads: Engaging nuts have Acme threads for rugged applications and for quick connection
Voltage: 500 VDC
Surface Finish: 32 finish
Appearance: Matte Black
Mating: Knurled Exterior Around Bayonet For Hand Tightening
IP Rating: IP-68, 20 Meter, 2 Hours, Per MIL-STD-810G Method 512.5
Plating: Black Nickel in accordance with MIL-DTL-26074, Grade A
